Harmar Highlander VPL
Innovation is at the heart of this next generation Vertical Platform Lift. The Highlander II is an outstanding choice for vertical lifting solutions in the home or in light commercial settings where an elevator is impractical or unnecessary.
Features:
- Guardian System: 4 bright, high-contrast LED status lights give continual performance feedback from the lift's control board. Monitoring almost every critical system, Guardian can provide immediate feedback and guidance.
- SteadyDrive: Ensures a smooth, quiet and stable lift.
- ReadyUPS System: True battery back-up option that can deliver at least 5-cycles in the event of power loss.
Lifting Capacity
750 lb
Standard Lift Height
53"
Maximum Lift Height Upgrade
171"
Arrives Assembled
Yes
Drive System
1" Diameter Acme Screw Drive
Optional Drive Systems
None Available
Battery Powered Option
Yes
Constant Pressure Platform Control
Yes
Emergency Stop Platform Control
Included
Alarm Button
Optional
Keyed Platform Control
Optional
Call-Send Controls
One Per Stop Included
Optional Call-Send Controls
Keyed and/or Wireless
Platform Type
Solid with Non-Skid Coating
Platform Size
36" x 48" (34" Usable Width)
Optional Platform Sizes
36" x 60" (34" Usable), 42"x 54" (34" Usable), 42" x 60" (40" Usable)
Platform Configuration
Straight-Thru Access
Optional Platform Configurations
Same Side Entry-Exit, 90 Degree Adjacent Access
Grab Rail
Included
Upper Access Ramp
None Available
Upper Landing Gate
Optional
Lower Access Ramp
36" Fixed or Auto-Folding Standard, Optional 42" Fixed or Auto-Folding
Guard Panel
36", Optional 42"
Maximum Stops
3
Lift Speed (FPM)
10
Other Options
Fire-Rated Doors, Automatic Door Openers
Portable
None Available
