AmeriGlide Hercules 750 Residential
The AmeriGlide Hercules 750 Residential Vertical Lift is the ideal vertical platform lift for outdoor or indoor applications. Great for porches, decks, and garages too! The non-skid epoxy coated floor and galvanized steel panel is weather resistant, even in the harshest conditions.
A 750 pound weight capacity comes standard on the Hercules, but a 1000-pound capacity is available as an option. Great for lifting large wheelchairs and two people at one time.
The acme screw direct drive makes the Hercules the smoothest and quietest lift on the market. Being battery powered, the lift and its automatic self-lowering folding ramp (standard) will even work during a power outage.
Safety features include under platform obstruction detection, emergency stop switch, anti-skid floor surface, emergency alarm, and much more.
To learn more about the Hercules 750 Residential Vertical Lift, call and speak with our experienced VPL experts today.
If you need a fully enclosed Vertical Lift, see our AmeriGlide Hercules 750 Commercial Enclosed Vertical Platform Lift.
Lifting Capacity
750 lb
Standard Lift Height
64"
Maximum Lift Height Upgrade
160"
Arrives Assembled
No
Drive System
Direct Drive ACME Screw
Battery Powered Option
Yes
Constant Pressure Platform Control
Yes
Alarm Button
Included
Platform Type
Non-skid (Epoxy crushed and recycled tires)
Platform Size
W 34"-36" x L 54"-60"
Optional Platform Sizes
Custom: W (31" to 42") x L (46" to 66")
Platform Configuration
Straight-Thru Access
Optional Platform Configurations
Same Side Entry-Exit, 90 Degree Adjacent Access
Grab Rail
Optional
Maximum Stops
3
Lift Speed (FPM)
9
Portable
Optional
